TES200 Integrated Circuit Tester 74 40 Series IC Tester Test Logic Integration can Judge The Quality of Logic Gates
4.6 (118 items)
Limited Time SaleUS$25.13 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210262840 | Release Date | 2026/04/02 | List Price | US$16.75 | Model Number | 210262840 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Description: The TES200 is a digital integrated tester that tests the 74 series and 40 series digital integration and can test more than 200 integrations. Simple to use, test logic integration can also determine which logic gate is bad. Select test integration by pressing a button. Applications: Digital integration test Technical Data Sheet: 1 Working voltage 7~12 VDC 2 working current <30 mA 3 Working temperature -40 ° C ~ 65 ° C Celsius 4 Storage temperature -40 ° C ~ 65 ° C degrees Celsius 5 Size Length X Width X Height：70X45X40mm Interface description and related operations JK1 power connector (DC head D13): It is inside and outside negative. Supply voltage (7 ~ 12V) DC regulated power supply. SW1 power switch ON: The power is on. OFF: The power is off. Key Description: MODE: Select the integration type. (74 series or 40 series) UP: Select the previous integrated model. DOWN: Select the next integrated model. TEST: Tests the selected integrated model. Note: When installing test integration, it is aligned downwards. Package: 1 digital integrated tester
- Working voltage 7~12 VDC
- working current <30 mA
- Working temperature -40 ° C ~ 65 ° C Celsius
- Storage temperature -40 ° C ~ 65 ° C degrees Celsius
- Size Length X Width X Height：70X45X40mm
| Model | TES200 |
|---|---|
| Brand Name | Jolooyo |
| Style Name | Digital |
| Manufacturer | JINGLUYAO |
| Power Source | Corded Electric |
| Upper Temperature Rating | 65 Degrees Celsius |
| Minimum Operating Voltage | 7 Volts (DC) |
| Global Trade Identification Number | 07545863780094 |
