A.D. International Z Type Caste Iron Angle Plate for Mini Vertical Milling Slide Mounted -Direct Fit for Mini Lathe Machine Tools
4.8 (37 items)
Limited Time SaleUS$21.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210013610 | Release Date | 2026/04/02 | List Price | US$14.00 | Model Number | 210013610 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This Z-Type Angle Plate is made from graded cast iron and is precision ground on all sides to ensure perfect perpendicularity and squareness. Designed to provide reliable support for your mini lathe, it features one base side with 2 counter-drilled holes and suitable stud bolts for securely clamping a mini vertical slide, while the opposite side has a continuous slot to fasten it through the lathe's toolpost stud. This versatile design makes it easy to mount the vertical slide and adjust the center height for precise machining. Ideal for hobbyists and professionals alike, the angle plate enhances your lathe's performance by ensuring stability and accurate positioning. Please review all product images carefully to ensure compatibility with your mini lathe model.
- High-Quality Graded Cast Iron: Made from durable, high-grade cast iron for superior strength and long-lasting performance.
- Precision Ground on All Sides: Each face is precision ground to ensure perpendicularity and squareness for accurate and reliable machining.
- Versatile Mounting Design: One base side features 2 counter-drilled holes with suitable stud bolts to securely clamp the mini vertical slide.
- Continuous Mounting Slot: The opposite side has a continuous slot for easy fastening to the lathe's toolpost stud.
- Perfect for Mini Lathes: Ideal for mounting a mini vertical slide to achieve the correct center height on your mini lathe.
- Enhances Precision: Provides stability and accuracy for your machining tasks, improving overall lathe performance.
- Compatible with Most Mini Lathes: Check all product images carefully to confirm compatibility with your specific lathe model.
| Size | Z Type Angle Plate |
|---|---|
| Color | Ground |
| Style | Z Angle Plate |
| Finish | 1 |
| Material | Caste Iron Body & Tool steel |
| Item Weight | 1.29 pounds |
| Part Number | 30-AP-1001 |
| Manufacturer | ADI |
| Power Source | hand_powered |
| Number Of Pieces | 1 |
| Item model number | 30-AP-1001 |
| Batteries Included | No |
| Batteries Required | No |
| Product Dimensions | 4.33 x 1.97 x 2.36 inches |
| Included Components | Z - Angle Plate & Bush |
| Warranty Description | 3 MONTHS |
| Item Package Quantity | 1 |
| Is Discontinued By Manufacturer | No |
